Mach 44 DTH Button Bits for Australia Mining Down The Hole Rock Drilling
The World's Leaders in Rock Drilling Equipment
DTH Hammers & Bits for any rock condition
Whatever conditions you're dealing with, our drill bits make the job easier. They are fitted with our proprietary cemented carbide buttons, which are designed to drill further. The drill bit bodies are made from precision hardened nickel molybdenum steel, with a compound curve shape for faster and smoother cutting and easier removal of cuttings.
Our well-proven button bit designs are trusted by customers around the world. The bits in the new range have an optimized head length with maximized steel support for the cemented carbide buttons, deep face grooves for excellent flushing and an aggressive cutting structure.
ROSCHEN offers a comprehensive range of WORLD CLASS quality grade DTH bits in global market, which were use in all rock types and drilling conditions. Bit life and rate of penetration are the most important criteria in selecting the right bit for a particular application.
DTH bits are available in sizes from 2" to 36". Bits come in three different standard bit head/face designs (Convex, Flat Face, and Concave), and with a number of tungsten carbide insert options, to guarantee a DTH drill bit that can tackle any challenge and rock-face formation. Additional bit head designs and custom options are available depending upon manufacturer.
Explore the subcategories below, view our online catalogs, or contact your ROSCHEN representative to learn more about our complete DTH Bit product offering.
| Bit Dia | Face | Guage Buttons | Face Button | Cone Button | Flush | Wt. | ||
| Inch | mm | design | Outer dia x No's | Inner dia x No's | Holes | kg. | ||
| 4.5 | 115 | Flat | 14 x 8 | 13 x 6 | 2 | 9 | ||
| 4.5 | 115 | Concave | 14 x 8 | 13 x 4 | 13 x 2 | 2 | 9 | |
| 4.5 | 115 | Convex | 14 x 8 | 13 x 4 | 13 x 3 | 2 | 9 | |
| 5 | 127 | Flat | 14 x 8 | 13 x 7 | 2 | 14 | ||
| 5 | 127 | Concave | 14 x 8 | 13 x 5 | 13 x 2 | 2 | 14 | |
| 5 | 127 | Convex | 14 x 8 | 13 x 4 | 13 x 3 | 2 | 14 | |
Roschen Rock Tools has emerged as a prominent business enterprise involved into manufacturing, supplying and exporting of quality striven products which include Rock Drilling Tools, Button Bits, DTH Hammer, Rock Drilling & Mining Equipment and many more. The firm got established in the year 2010 as a Sole Proprietorship business concern and is located in Cherlapally, Hyderabad, Andhra Pradesh. The entire range is used in various industries for its effective and huge applicability. We aim at providing best quality product to our clients to ensure they face no issues while applying these products to their use. Our manufactured products are hugely cherished in market owing to their sturdy construction, reliable operations, longer functional life and corrosion resistance. Moreover, their simplicity in operation and low maintenance has made them very popular amongst clients. All these qualities certainly give us an edge over our competitors ensuring our popularity even further.
| ROSCHEN DTH Bits Specifications | ||||
| Hammer Size | Bits diameter | Shank | ROSCHEN CODE | |
| Metric | Inch | |||
| 1" | 64mm-70mm | 2 1/2"-2 3/4" | BR1 | ROS 11 |
| 2" | 70mm-95mm | 2 3/4"-3 3/4" | MACH20/BR2 | ROS 22 |
| 3" | 90mm-102mm | 3 1/2"-4" | COP32/COP34/MACH303 | ROS 32 |
| M30/DHD3.5/BR3 | ROS 34 | |||
| 4" | 105mm-152mm | 4 1/8"-6" | COP44/DHD340/MACH44 | ROS 42 |
| SD4/M40/QL40 | ROS 44 | |||
| 5" | 133mm-165mm | 5 1/4"-6 1/2" | COP54/DHD350R/MACH50 | ROS 52 |
| SD5/M50/QL50/BR5 | ROS 54 | |||
| 6" | 152mm-254mm | 4 1/8"-10" | COP64/DHD360/SD6 | ROS 62 |
| M60/QL60/Bulroc BR6 | ROS 64 | |||
| 8" | 203mm-330mm | 8"-13" | COP84/DHD380/SD8 | ROS 82 |
| QL80/M80/M85 | ROS 84 | |||
| 10" | 254mm-380mm | 10"-15" | SD10 | ROS 100 |
| NUMA100 | ||||
| 12" | 305mm-508mm | 12"-20" | DHD1120/SD12 | ROS 120 |
| NUMA120/NUMA125 | ||||
| Notes: Any special size of DTH bits will be available by requests. | ||||
| Metzke, Remet thread is available! | ||||
FAQ
Terms & Conditions of Ordering:
Quality warranty:
Our products are made of high quality steel and all spares parts are inspected strictly before shipping. We have quickly responses for your complaint and suggestion.
Package:
Using ply-wooden cases and pallet for package to protect the products and avoid the damage during transportation. Also we can customize package according to your special requests.
Production time:
Generally need 15-25 days
Transportation:
By air, By Express or By sea according to your requests.
1. Methods of Payment:
T/T (Telegraphic Transfer) or Western Union or L/C at sight
2. Handling time for an order
Based on order quantity, normally it takes 20 days for production.
in 3 working days after receiving the advance payment
3. Shipping way
Sample order: we suggest Courier express like DHL/UPS/TNT/FEDEX or by air
Bulk order: we suggest by air or by sea.
4. Quality Control
We have our own experienced QC.
There will be strict inspection and testing for every order before shipping out.
5. After Services:
a. Our sales team will response for your question within 24 hours (Holidays Excluded)
b. Technical Support will be available in any time
6. Quality & Service:
A. There will be strict inspection and testing for every order before shipping out.
B. Our sales team and Technical Support will response for your question within 24 hours through skype: ROSCHEN.TOOL and WhatsApp/Wechat: +86-13764195009
C. Free replacement will provide once the failure confirmed caused or our product quality; Not satisfied with a refund.
